Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in producing in manufacturing construction machinery. machinery such as boom lifts, aerial lifts and manlifts. These machinery are designed to facilitate access to places that are difficult to reach, large equipment, roofs and buildings, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and contains handholds or platforms or steps which are connected to the unit to be able to move workers from each floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model provides a reach of seventy feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height measures at 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
